Description: Model: CYS-S8218 Item Name: 40Kg Digital waterproof servo Weight 164g ± 1 g Size 59.5*29.2*55.2mm Control System ( )Pulse Width Control 1500usec Neutral Operating Voltage 6.0~7.4Volts Operating Temperature Range (-)10 to 50 degree C Operating Speed (6.0V) 0.20sec/60° at no load Operating Speed (7.4V) 0.18sec/60° at no load Stall Torque (6.0V) 38kg.cm Stall Torque (7.4V) 40kg.cm Operating Angle 45deg. one side pulse traveling 500 usec Direction Anticlockwise/Pulse Traveling 1000~2000usec Current Drain (6.0V) 20mA/idle and 180mA no load operating Current Drain (7.4V) 20mA/idle and 200mA no load operating Stall Current 7.5A/8.6A Dead Band Width 4usec Motor Type NdFeB motor Bearing Type Dual Ball Bearing Horn gear spline 17T Gear Type Metal Connector Wire Length 300mm ± 5mm Wire info Brown/Black = Negative Red = Positive Orange/White = Signal
